The Delta 1000 is truly universal because the bed frame can be used with Drive's and most other manufacturers’ bed ends, old and new
The transition box mounted on the foot section is key to interchangeability (Figure A)
The transition box allows you to change the rotation of the high/low shaft
Headboard is taller than footboard to better fit home decor (Figure B)
The wood grain panels are break and scratch resistant
Once installed, the high/low shaft will stay with the bed to eliminate loss or forgetting on future installations (Figure C)
Labels and color-coded springs assure accurate installation of side rails for patient safety (Figure D)
Unique motor is completely self-contained to reduce weight and noise
9 ½" to 23 ½" deck height
Easy to set up
Top mounted Hi/Lo crank accessibility
Height-adjustable motor comes pre-installed on the foot section
Caster easily moves from standard to low bed position
The motor assembly can be installed and removed with patient in bed
Bed, side rails and mattress safety-tested by SGS, a nationally recognized testing facility Satisfies all applicable FDA entrapment guidelines
The motor is UL approved
In the event of a power failure, a 9 volt battery, located in the hand control, can lower the head and foot sections nine times
New and improved hand pendant has large, easy-to-use controls (Figure E)
Bed ships in two cartons
Hand crank located on the top of the footboard prevents bending for the caregiver when in the low position (Figure F)
Channel frame construction provides superior strength and reduced weight
Zinc-coated spring deck
Extension kit available (model #15030EXTKIT) extends length from 80" to 84"
Patent Pending
Weight Capacity 450 lbs
